Application and Features
- Compact and light machine for limited space jobs.
- Angle drill stand (45 degree backward) as standard accessory.(AB42)
- Normal Stand Column: 800 mm (31”) with 557 mm (22”) stroke.
- 40 x 40 mm (1-5/8” x 1-5/8”) square column. Includes water collector ring.
- Optional spindle adaptor for each countriesʼ circumstances.
Additional information
| APPLICATION MATERIAL |
Asphalt, Cement, Concrete, Cured Concrete, Green Concrete, Medium Hardness of Concrete, Reinforcement Concrete |
|---|---|
| MOTOR MODEL | |
| POWER RATED |
1,100W |
| NO. LOAD SPEED (RPM) |
970rpm |
| RATED LOAD SPEED (RPM) |
650rpm |
| PREFERRED CORE BIT DIAMETER (MM) |
60 – 120mm |
| BASE TYPE |
Swivel Anchor (AB42) |
| BASE SIZE |
146 x 200mm |
| COLUMN HEIGHT |
800mm |
| TRAVEL LENGTH |
548mm |
| BRAND | |
| WEIGHT |
9.6kg |
