FP Gasoline Generator Set (II)

FP Gasoline Generator Set (II)
FP Gasoline Generator Set (II)

FP Gasoline Generator Set (II)

Product Code: FP4000G
Availability: Pre Order
Loading ...
Share:
Gasoline Generator Set Model FP4000G (3.0Kva)                         FP4000G (3.5Kva)
Engine Model GX270
Engine Type Air-Cooled 4-Stroke OHV 25⁰ Inclined Single Cylinder
Bore x Stroke 77 x 58mm
Displacement 270cm³
Compression Ratio 8.2 : 1
Max. Power Output 9HP / 3600rpm
Recommended Power Output 8.2HP / 3600rpm
Ignition System Transistorized Magneto
Starting System Recoil
Fuel Tank Capacity 6 Litre
Air Cleaner Semi Dry, Oil Bath, Duel, Silent, Cyclone
Oil Capacity 1.1 Litre
Fuel Consumption 230g/hp-hs(313g/kWh)
Dimension (mm) 380x430x410
Alternator Model TFD-3                                             EP 2 95H (Sincro)
Rated Output 3.0Kva                                                   3.5Kva
Maximum Output 3.6Kva                                                   4.3Kva
Rated Voltage 220 V                                                      230 V
Frequency 50Hz                                                       50Hz
Weight 23KG                                                      19KG
