HHM Portable Dust Collector UB-50P
Product Code: UB-50P
Availability: In Stock
RM0.00
Portable Dust Collector UB-50P
1. Industrial quality motor and specially designed blower impeller for maximum performance.
2. Each caster allows for total mobility.
3. Dust collector bags always come with an elastic band for 30 micron filter bag for easy installation.
4. Metal strap bag clamp will tie up collection bag completely.
5. Extensive line of accessories to control the toughest dust collecting jobs.
6. Solid and rigid housing design for the blower system.
Technical Specification:
| MODEL | UB-50P | |
|---|---|---|
| Motor | 1 HP / 60 HZ | 0.75 KW / 50 HZ |
| Impeller Size | 10-1/2″ | 267 mm |
| Air Suction Capacity W/O Bag | 750 CFM | 1000 m3/h |
| Max. Static Pressure | 5.6 InH20 | 142 mmAq |
| Inlet Diameter | 4″ x 1 | 102 mm x 1 |
| Bag Capacity | 15 gallons | 60 liter |
| Noise Rate (@3M) | 70 dB | |
| Overall Size (L x W x H) | 1100 x 400 x 500 mm | |
| Packing Size (L x W x H) | 472 x 402 x 464 mm | |
| N.W. / G.W. / Cuft | 20 kgs / 22kgs / 3.2′ | |
| 20 FF Container (Sets) | 328 Sets | |
