Product Code: HD 9/23 De
Availability: In Stock
RM0.00
Loading ...
Share:

Ideal wherever difficult external conditions and demanding cleaning tasks meet: the HD 9/23 De diesel-powered cold water high-pressure cleaner with Yanmar diesel engine generates the electricity it needs itself. If necessary, the required water can also be suctioned directly from bodies of water, allowing you to work in areas with poor infrastructure. With a water pressure of 230 bar, the machine measures up to almost any task. Its ergonomic frame concept and the puncture-proof wheels guarantee maximum mobility, while the robust basic frame can withstand heavy-duty use. With the EASY!Force high-pressure gun, which makes use of the recoil force of the high-pressure jet to reduce the holding force for the operator to zero, as well as the EASY!Lock quick-release fasteners, which make set-up and dismantling five times faster than with conventional screw connections, the machine is very convenient to use. A large water filter and a thermostat valve are built in to protect the pump. Useful optional enhancements, like the extra cage frame with eyelets for crane loading, round off the machine.



FEATURES AND BENEFITS

High pressure washer HD 9/23 De: Maximum independence

Maximum independence

Fitted with reliable Honda or Yanmar motors for use without an external power supply. Can suck up water – e.g. from lakes or ponds – and use it for cleaning.



High pressure washer HD 9/23 De: Optimum ease of use

Optimum ease of use

The ergonomic frame concept makes transport on uneven ground easier. Storage possibilities for all accessory parts directly on the machine. Puncture-proof wheels guarantee permanently high mobility.



High pressure washer HD 9/23 De: Highly versatile

Highly versatile

Optional cage frame with eyelets for crane loading reliably protects the machine. Hose reel attachment kit for shorter set-up & finishing-off times available as an optional extra. Portable version with robust tubular frame specially designed for painters and plasterers (HD 728 B).



For the toughest jobs
  • Robust basic frame for daily use in tough conditions.
  • Large water filter to protect the pump.
  • Thermostat valve to protect the pump from overheating in recirculation mode.
SPECIFICATIONS

Technical data

Flow rate (l/h) 400 - 930
Working pressure (bar/MPa) 40 - up to 230 / 4 - up to 23
Motor type L 100 N / diesel
Engine manufacturer Yanmar
Weight (kg) 105.3
Dimensions (L × W × H) (mm) 800 x 700 x 800

Equipment

  • Spray gun, EASY!Force Advanced
  • High-pressure hose, 15 m
  • Spray lance, 1050 mm
  • Power nozzle
  • Infinitely variable pressure and water flow regulation
  • Electro start
  • Servo Control
  • Motor, Diesel
