Product Detail
| Model | 5GF-M/ME | 5GF-M/ME3 | 6GF-M/ME |
| Frequency | 50/60Hz | 50/60Hz | 50/60Hz |
| Max.Ac Output (kW) | 4.8/6.0 | 5.5/7.5 | 6.3/6.5 |
| Rated Ac Output (kW) | 4.4/5.74 | 5.0/6.0 | 5.8/6.0 |
| DC Output (V-A) | 12V/8.3A | 12V/8.3A | |
| Rated Voltage (V) | 220 | 220/380 | 220 |
| Power Factor | 1.0 | 0.8 | 1.0 |
| Phase | Single Phase | Three Phase | Single Phase |
| Excitation System | Self-excitation | ||
| Dimension (LxWxH) mm | 760x500x650 | ||
| Neit Weight (Kg) | 120 | 190 | |
| Engine Model | LT186F | LT188FD | |
| Type | Single-cylinder; vertical; 4-stroke; Air-cooled; direct-injection | ||
| Displacement (cc) | 406/418 | 455 | |
| Fuel Tank Capacity | 15 | ||
| Lube.Oil Capacity | 1.65 | ||
| Starting System | Manual/Electrical Optional | ||
| Low Oil Alarm System | With | ||
