| Model | SNB-50x | SNB-80x | SNB-100x |
| Shaft | Key/Thread | Key/Thread | Key/Thread |
| Outlet size | 50(2") | 80(30") | 100(4") |
| Inlet Size | 50(2") | 80(30") | 100(4") |
| Power (hp) | 5.5 | 6.5 | 8 |
| Speed (rpm) | 3600 | 3600 | 3600 |
| Max. Capacity (L³/min) | 700 | 1000 | 1600 |
| Lift (m) | 36 | 36 | 25 |
| Suction (m) | 8 | 8 | 8 |
| Pump Body | Aluminium Alloy | Aluminium Alloy | Aluminium Alloy |
| Weight (kg) | 6 | 10 | 14.5 |
| Dimension | 330x225x230 | 435x260x250 | 470x350x280 |
