Alternator Model: EP2C5T
AC max output (KVA): 5.5
AC rated voltage (V): 230
Frequency: (Hz): 50
Voltage adjustment: Condenser
Options of engines to be assembled with the above alternator:
| No | Brand | Model | Fuel | Max. Output (hp) |
Fuel Tank Capacity (lit) |
Total Net Weight (kg) |
Diamension (mm) (L)x(W)x(H) |
Starting System |
| 3.1 | Honda | GX390 | Gasoline | 13.0 | 6.1 | 68 | 725 x 495 x 560 | Recoil |
| 3.2 | Robin | EX40 | Gasoline | 14.0 | 7.0 | 68 | 865 x 530 x 600 | Recoil |
| 3.3 | Launtop | LA186 | Diesel | 10.0 | 5.5 | 83 | 725 x 495 x 560 | Electric |
| 3.4 | Yanmar | L100 | Diesel | 10.0 | 5.4 | 83 | 725 x 495 x 560 | Recoil |
