MELLO TIG-200A (IGBT) INVERTER TIG/MMA MACHINE

  1. Home
  2. Product
  3. Welding Product
  4. Mello
MELLO TIG-200A (IGBT) INVERTER TIG/MMA MACHINE
MELLO TIG-200A (IGBT) INVERTER TIG/MMA MACHINE

MELLO TIG-200A (IGBT) INVERTER TIG/MMA MACHINE

Product Code: TIG200A
Availability: Pre Order
Loading ...
017 432 8850019 209 0701
Share:
ITEM / MODEL UNIT TIG-200A
Input Power Voltage / Freq V/Hz AC240V / 50Hz
Rate Input Power Capacity KVA 4.7
Rated Input Current A 21.5
No-load Voltage  V 56
Rated Output Current A            MMA : 10~160    TIG : 10~160
Rated Output Voltage V       MMA : 26.4          TIG : 16.4
No-load Consumption W 60
Duty Cycle (25ºc) % 60
Efficiency % 85
Power factor (cosØ)   0.93
Insulation class   F
Protection class S IP21S
Arc-starting   HF
Postflow Time S 2.5 / 5
Weight (G.W / N.W) kg 9.7/ 6.8
Size (L x W x H) (CTN) mm 450 x 270 x 345
Accessories   1. Power cable 3M with 13A 3-pin plug.
2. Front Panel with KDP16 socket.

3. 300A Earth clamp with 3M 16mm² welding cable & KDP16 plug.

4. WP17 TIG Torch (Single line) 4M with set accs.
5. 3M 5/16'' hose with 2pcs hose clip.
6. KDP16 Male 1pc.
