MELLO TIG315PW AC/DC(MOS)3 PHASE INVERTER WITH TROLLY & WATER COOLER TIG WELDING

  1. Home
  2. Product
  3. Welding Product
  4. Mello
MELLO TIG315PW AC/DC(MOS)3 PHASE INVERTER WITH TROLLY & WATER COOLER TIG WELDING
MELLO TIG315PW AC/DC(MOS)3 PHASE INVERTER WITH TROLLY & WATER COOLER TIG WELDING

MELLO TIG315PW AC/DC(MOS)3 PHASE INVERTER WITH TROLLY & WATER COOLER TIG WELDING

Product Code: TIG315PW AC/DC
Availability: Pre Order
Loading ...
017 432 8850019 209 0701
Share:
ITEM\MODEL UNIT TIG 315PW AC/DC
Input Power Voltage / Freq. V/Hz AC415V 50/60
Rate Input Power Capacity KVA 9
No-Load Voltage V 45
Output Current Range A 10-315
Duty Cycle (25ºc) % 60
Arc-Starting   HF
Efficiency % 85
Power Factor (cos Φ)   0.93
Insulation Class   F
Weight KG 66
Dimension (L x W x H) mm 900 x 360 x 835
Protection Class   IP23
Water Cooler Tank   Build In
Clean Width % 20-80
Down-Slope Time S 0-10
Postflow Time S 1-10
Remote Control   YES
Base Current  A 10-315
Pulse Frequency Hz 0.5-10
Welding Thickness mm 0.8-8
Accessories   5M WP-18 TIG Torch,
Earth Clamp with 3M x 35MM2
Cable, 3M 4x2.5MM2 Power Cable.
