TAIWAN WINCH ELECTRIC CHAIN HOIST CH-1102-10A03

TAIWAN WINCH ELECTRIC CHAIN HOIST CH-1102-10A03
TAIWAN WINCH ELECTRIC CHAIN HOIST CH-1102-10A03

TAIWAN WINCH ELECTRIC CHAIN HOIST CH-1102-10A03

Product Code: CH-1102-10A03
Availability: Pre Order
Loading ...
Share:

Features:

  •  Employs imported FEC80 class high strength heat treated alloy steel chain.
  •  LIMIT SWITCH POSITIONS: Limit switches are provided at lift-up and down stroke to prevent poor smoothness of chain or loosening while ensuring safety.
  • Equipped with magnetic contactor to avoid voltage drop, while ensuring powerful lifting.
  •  24V LOW VOLTAGE DEVICE: In case electric shock from swith, the low voltage device may avoid accident.
  •  Specially designed DC magnetic brake.
  •  Upon request, additional electronic overload protector and emergency stop switch.
  •  In case of power failure, the DC magnetic brake actuates immediately.
  • Emergency stop function switch is available upon request
Model CH-1102-10A03 CH-1105-06A03 CH-1105-10A03 CH-1110-06B03 CH-1220-03B03 CH-3120-06C03
Capacity (KGS) 250 500 500 1000 2000 2000
Lift (M) 3
Hoisting Speed
(M/min)
50HZ 8.9 5 8.9 5 2.5 5.7
60HZ 10.7 6.1 10.7 6.1 3 6.9
Hosting Motor (KW) 0.55 0.55 0.75 0.75 0.75 3.7
Chain dia x Pitch FEC Ø6.3X19 Pitch FEC Ø7.1X21 Pitch FEC Ø10.0X30 Pitch
Chain Falls Line 1 2 1
Power Source 1PH 220V~240V 3PH 220V~440V
Approx Weight (KG) 34 34 34 35 44 83
Approx. Dimensions(mm) A 235 235 235 235 235 300
B 119 119 119 119 119 159
C 445 445 460 460 460 592
D 231 231 246 246 246 314
E 520 520 520 520 520 575
F 31 31 31 31 31 38
G 42.5 42.5 42.5 42.5 42.5 65
H 85 85 85 85 85 129
I 31 31 31 31 31 38
J 20 20 20 20 20 31
B1 116 116 116 116 116 141
D1 214 214 214 214 214 278
