Product Code: WS-6025MT
Availability: Pre Order
Loading ...
Share:

Model: WS-6025MT (Made in Taiwan)
Portable magnetic drilling machine with 2 speeds and MT-3 taper holder

Price inclusives 6%GST.

Features

  • Speed Control: Machine is designed with low and high-speed options that allows the operator to make an appropriate choice for R.P.M.
  • Tool adaptor design: Applicable on Annular Cutter & Twist Drill.
  • Dual Coil Magnetic Base
  • Arbor Support Bracket
  • Regulated PC Board for switch.

Specifications

Voltage  220 ~ 240V 50Hz
Motor Rated Power Consumption  1850W
Motor Rated Ampere 7.5A
No Load Speed (2 speeds) High Speed: 720rpm
Low Speed : 400rpm
Tool Adaptor Inner Diameter 19.05mm
Adjustable in height for Max. Stroke  150mm
Coolant Supply via Tool Holder
Magnet Power Consumption 85W
Magnet Adhesion 22540N or 2300kgf
Magnet Dimensions (L x W x H) 210mm x 100mm x 64mm
Weight 23kg
Cutting Capacity Accular Cutter: 18-60mm
Twist Drill: Max. 25mm

Standard Accessories



  • MT-3 with annular cutter holder
  • Handdle
  • Double open end wrench
  • Hex key
  • Machine manual
