Xest Ling Radial Arm Drill 32mm 1500W 2200rpm 1830kg Z3032X10/1

Product Code: Z3032X10/1

Availability: Pre Order

Model: Z3032X10/1
Radial arm drilling machine with spindle speeds range from 32 to 2500rpm.

Price inclusives 6%GST.

Features

With wide range of speed, with manual power feeds. The feed of machines are very easily engaged and disengaged at any time.
The radial arm can rotated and can tilted 45±°,it reliable and easy job can be done.
Main parts are made by machine center which import from KIA with high precision and efficiency, ensuring reliability and high quality.
The machine with small appearance and much function, the machine are widely used for drilling, counterboring, reaming,tapping and etc.

Specifications

Max. Drilling Capacity	Cast Iron: 32mm Steel: 25mm
Max. Tapping Capacity	Cast Iron: M20 Steel: M16
Diameter of Column	240 mm
Spindle Travel	280 mm
Distance Spindle Axis to Column Generating Line	300~1000mm
Max. Distance Spindle Nose to Working Surface of Base	220~1000mm
Spindle Taper	MT4
Spindle Speeds Range	32~2500rpm
Spindle Speeds Series	8
Spindle Feeds	0.1~1.25 mm/r
Rotary angle of rocker in horizontal plane ( ° )	360°
Dimensions of Worktable Surface	600mm x 450mm x 450mm
Dimensions of Base	1710mm x 800mm x 160mm
Dimensions of Overall	1760mm x 800mm 2050mm
Motor	2200 W
Volts	380V Three Phase
Weight	1830 kg
